Model Information Configuration Status VStandard,△Optional ,×None Abnormal data in red | NTB45U-C | ||
Basic Performance Parameters | Buckct capacity(m³) | 0.06 | |
Travel speed low/highspced(Km/h) | 0-4 | ||
Climbing ability(%) | 30 | ||
A Maximum Digging Height(mm) | 3453 | ||
B Maximum Unloading Height(mm) | 2366 | ||
C Maximum Digging Depth(mm) | 2570 | ||
EMax.digging radius(mm) | 4250 | ||
Side Swing | √ | ||
Side Swing Angle(L/R) | N/A | ||
undercarriage expansion | X | ||
Body | J Overall Lcngth(mm) | 4181 | |
K Overall Width(mm) | 1500 | ||
L Overall Height(mm) | 2450 | ||
Bulldozer Width/Hcight | 1500/200 | ||
Engine | Engine Brand | Yanmar | |
Engine Model | 403J-11/3TNV88F | ||
Max.powen(Kw) | 18.4 | ||
Max.speed(pm) | 2800 | ||
Cylinders | 3 | ||
Cooling mcthod | water cooling | ||
Engine oil change quantity(L) | 3.8 | ||
Fucl Type | Diesel | ||
Hydraulic system | Main pump type/mode | Pistonpump/40 | |
Main pump brand | Long Gong | ||
Rated set pressurc(Mpa) | 20 | ||
Maximum flow rate of main pump(L/min) | 72 | ||
Multi-way valve | 8-way valve | ||
Brand of Multi-way valve | (Long Gong) | ||
Rated Set Pressure(Mpa) | 22 | ||
Hydraulic Lincar Motor type | KTM03CJ | ||
Linear Motor Brand | Like Chuan | ||
Hydraulic Servo Motor type | 2.5K-245 | ||
Excavator tracks | -Rubber(bandwidth*pitch*number of sections | 250*52.5*80 | |
Configuration | Cab | √ | |
Roof | X | ||
Handrail | √ | ||
Thumb Clip | √ | ||
Counterwcight | √ | ||
Tensioning Forms | Spring tension | ||
Air Conditioning | √ | ||
Tank | Fuel tank(L) | 16 | |
Hydraulic oil tan(L) | 20 | ||
