Mini Skid Steer Loader

Home >  Products >  Mini Skid Steer Loader

Mini Skid Steer Track Loader | AGT Industrial KBT/KRT23 Türkiye

Product Description

The AGROTK Construction Machinery B&S Engine Front End Mini Skid Steer Loader is the ideal device for anybody searching for effective and efficient machinery on the construction internet web site. This mini skid steer loader includes a flexible and effective B and S engine that's developed to final and manage any type of task internet web site. Particularly developed to offer security is ideal efficiency on any type of landscapes, creating it an essential for practically any type of construction internet web site. It truly is geared up along with a loader is front-end can definitely manage excavation jobs, launching, and eating products, transferring all of them in the direction of the preferred place along with simpleness. Among the extremely noteworthy functions is its own dimension is small is ideal for operating in slim or even hard-to-reach locations. Its own dimension likewise creates it simple to transfer coming from one place to another, creating versatility concerning the construction site a wind.

The loader's mini dimension doesn't concession its own energy, as it works at dealing with hefty great deals of up to 600kg easily. This work, integrated along with its own durable engine, equips the driver to finish any type of job rapidly and efficiently, conserving a long-time labor sets you back. Likewise packed along with easy to use manages. Its own active motion and trip is soft it easy appropriate to run the devices, consisting of beginners or even those along with restricted expertise. Security is simply a concern is leading off, and likewise this mini skid steer loader doesn't dissatisfy within this particular element. It includes a choice of top-quality security functions, like automated features being cut-off protected chairs, back-up alarm systems, and roll-over security.

AGROTK Construction Machinery B and S Engine Front End Mini Skid Steer Loader is an outstanding option for any type of construction internet web site. It is an effective, flexible, and maneuverable device that offers security, dependability, and simplicity of utilization. Its own small dimension, durable engine, higher value capability, and easy to use manages create it stand apart coming from the remainder. Spend within this particular machinery today, and expertise the distinction it will create in your construction internet web site procedures.

Specifications
Model Information
Configuration Status
√Standard,
Optional ,×None
Abnormal data in red
KBT Series
KBT23 KRT23
Basic
Performance
Parameters
Working Weight(kg) 905 905
Bucket capacity(m³) 0.12 0.12
Travel speed low/high speed(Km/h) 3 3
Climbing ability(%) 30 30
Maximum lifting force (Kg) 220 220
C Maximum working height(mm) 2450 2450
B Maximum pin height (mm) 1800 1800
A Maximum unloading height(mm) 1350 1350
G Loading distance at maximum unloading height (mm). 840 840
H Wheelbase(mm) 690 690
F Ground clearance(mm) 120 120
L Bucket discharge angle 20° 20°
Body E Bucket width(mm) 812 812
J/K  Overall Length(mm) 2180/2330 2180/2330
N  Overall Width(mm) 820 820
O Body width(mm) 810 810
D Overall Height(mm) 1420 1420
M Slewing radius(mm) 1400 1400
Engine Engine Brand B&S Rato
Engine Model 23HP 740
Max. Horsepower(pc) 23 23
Maximum power(Kw) 16.79 16.8
Max. speed(rpm) 3600 3600
Displacement (cc) 627 739.3
Cylinders 2 2
Cooling method fan cooling fan cooling
Engine oil change quantity(L) 1.7 1.6
Fuel Type Gasoline Gasoline
Fuel Grade 92# 92#
Theoretical fuel consumption(L/h) × ×
Hydraulic
system
Main pump type/model gear pumps gear pumps
Main pump brand (Tianjin Xingzou) (Tianjin Xingzou)
Rated set pressure(Mpa) 22 22
Maximum flow rate of main pump(L/min) 75.6 75.6
Multi-way valve Two sets of 3 manual valves Two sets of 3 manual valves
Brand of Multi-way valve (Li Xin) (Li Xin)
Rated Set Pressure(Mpa) 16 16
Hydraulic Linear Motor type Cycloid hydraulic motor Cycloid hydraulic motor
Linear Motor Brand (Dan  Fusi) (Dan  Fusi)
Motor Displacement 350 350
Tracks -Rubber (bandwidth*pitch*number of sections) 200*72*32 200*72*32
Wheels
Configuration Cab × ×
Roof × ×
Handrail
Tensioning Forms Hydraulic Tensioning Hydraulic Tensioning
Air Conditioning × ×
Fuel tank Fuel tank(L) 18 18
Hydraulic oil tan(L) 30 30
